Specifications
Material
Platform: Carbon Steel;Terminal: Plastic
Protection Rating
IP54 Terminal;IP65 Platform
Display
7 segment LCD with backlit
Interfaces
RS232
Housing
Platform: Carbon Steel;Terminal: Plastic
Application Software
Dynamic weighing;Counting;Simple weighing;Over Under Checkweighing
Hazardous Approval
No
Applications
Simple Weighing;Dynamic weighing;Counting;Over Under Checkweighing
Data Interface
Serial
Dimensions/Platform Size
from 15.8" to 19.7";from 401 to 500 mm
Environment
Dry (<IP65)
Hazardous Area
Non-hazardous area
Scale Interface
Analog
Voltage
Battery Version;AC Version
Hygienic Design
No
Performance Optimization
Reliable Weighing Technology: Robust aluminum strain gauge load cell
Data Management
Printing: Application specific print templates
Versatility
Good Readability: LCD-Display with backlit;Mobile Operation: Battery optional available;Bench Scale: For versatile weighing tasks in dry environment
Platform Type
Bench Scale
EasyPrint Name
BBA231-3B60A
Maximum Capacity
60 kg
Readability
5 g
Repeatability (sd)
2.7 g
Platform Size
15.7 in
Platform Size
400 mm
Platform Size
19.7 in
Platform Size
500 mm
Platform Size
3.11 in
Platform Size
79 mm
Repeatability
5 g
Repeatability, typical
2.7 g
Repeatability, (typical)
0.006 lb
Weighing Pan Dimensions
1.93 in
Weighing Pan Dimensions
49 mm
Weighing Pan Dimensions
15.7 in
Weighing Pan Dimensions
400 mm
Weighing Pan Dimensions
19.7 in
Weighing Pan Dimensions
500 mm
Cable {Length}
6.5 ft
Cable {Length}
2 m
