Specifications
Material
Aluminium diecast
Protection Rating
IP54
Hazardous Approval
No
Scale Interface
SICSpro
Dimensions/Platform Size
</=400 mm;from 6.3" to 15.7"
Environment
Dry (<IP65)
Hazardous Area
Non-hazardous area
Legal for Trade
OIML
Hygienic Design
No
Performance Optimization
For Best Performance: High resolution monobloc load cell;Easy Scale Leveling: For fast & precise leveling;FACT: Fully automated calibration
Versatility
Versatile Digital Platform: For demanding tasks in dry environment;Plug & Play Functionality: Ready to weigh straight from the box
Legal for Trade Class OIML
Class II
Platform Type
Bench Platforms
EasyPrint Name
PBK785-0.6XS
Maximum Capacity
1.2 lb
Maximum Capacity
0.61 kg
Readability
0.000002 lb
Readability
0.001 g
Repeatability (sd)
0.000002 lb
Repeatability (sd)
0.0008 g
Platform Size
9.7 in
Platform Size
247 mm
Platform Size
8.1 in
Platform Size
206 mm
Platform Size
3.7 in
Platform Size
95 mm
Readability (Certified)
0.01 g
Repeatability
0.02 lb
Repeatability
0.001 g
Repeatability, typical
0.0008 g
Repeatability, (typical)
0.000002 lb
Readability (Certified) Standard
0.01 g
Cable {Length}
3.3 ft
Cable {Length}
1 m
Linearity (typical)
0.00001 lb
Linearity, typical
0.002 g
Eccentric Load Deviation at 1/3 of Full Load (typical)
0.00001 lb
Error of Indication at full load (typical)
0.00001 lb
Error of Indication at full load (typical)
0.002 g
Key features
- Eccentric Load Deviation at 1/3 of Full Load (typical) {Metric}: 0.003 g
INQUIRY
Get a tailored quote for the Bench Scale PBK785-0.6XS.
Tell us the application, throughput, and any compliance requirements. An LDY account manager assigned to Food & Feed will respond within one business day.
· Industrial Scales & PlatformsBench Scale PBK785-0.6XS
