Specifications
Material
Mild Steel (epoxy painted, smooth plate deck finish)
Protection Rating
IP69k (Dry)
Hazardous Approval
No
Scale Interface
Analog
Floor Scale Type
Floor Scales;Special Application Floor Scales
Suspension
Rocker Pin and Slider Cup;Centerlign Suspension
Environment
Dry (<IP65)
Hazardous Area
Non-hazardous area
Legal for Trade
NTEP;OIML
Dimensions/Platform Size
>60";>1,501 mm
Performance Optimization
Reliable Weighing Technology: Robust stainless hermetic seal load cell
Versatility
Heavy Capacity Platform: For heavy duty application in dry environment
Legal for Trade Class NTEP
Class III
Legal for Trade Class OIML
Class III
Platform Type
Floor scale
EasyPrint Name
MG4500106865
Hygienic Design
No
Maximum Capacity
40,000 lb
Maximum Capacity
20,000 kg
Readability
5 lb
Readability
5,000 g
Readability (Certified)
10 lb
Readability (Certified)
10,000 g
Repeatability
4 lb
Repeatability
2 kg
Platform Size
96 in
Platform Size
2,440 mm
Platform Size
72 in
Platform Size
1,830 mm
Platform Size
8.38 in
Platform Size
213 mm
Dimensions
96 in
Dimensions
2,440 mm
Dimensions
72 in
Dimensions
1,830 mm
Dimensions
8.38 in
Dimensions
213 mm
Repeatability, typical
2 kg
Repeatability, (typical)
4 lb
Repeatability (sd)
4 lb
INQUIRY
Get a tailored quote for the Floor Scale MG4500 S MS 40K 72X96.
Tell us the application, throughput, and any compliance requirements. An LDY account manager assigned to Food & Feed will respond within one business day.
· Industrial Scales & PlatformsFloor Scale MG4500 S MS 40K 72X96
