Specifications
Measuring range
1*10-6 – 5*10-2 mol/L
Connector
S7
Type of junction
--
Shaft Material
PPS
Sensor Type
Combined electrode
Parameter
GSE
Type of membrane
Polymer
Intelligent Sensor Management (ISM®)
No
Temperature probe
No
Signal type
Analog
Ion
Ammonia (gas)
Shaft length
120 mm
Shaft Diameter
12 mm
Temperature Range
0 °C – 50 °C
Optimal pH range
11 – 14
Connector on Sensor
S7
Connector to Meter
Flexible (detachable cable)
Cable Included
No
Ion Type
Gas
Recommended Meters
SevenGo Duo;SevenDirect;Seven2Go;NineFocus
Recommended Meter Models
SG68;SG78;S8;SG98;SD50;NF5000
Unique Sensor Purpose
Best Choice for NH3
