Load Cells & Weigh Modules
Weigh Module SWB220 CS 1.25K
SWB220 Weigh Modules are suitable for general purpose static weighing of OEM machinery, conveyors, tanks and hoppers with limited lateral movement.
Specifications
Material
Zinc Plated
Metrology
OIML C3, NTEP III 5M
Load Cell
SLB215
Hazardous Approval
ATEX, FM
Protection Rating
IP68
Maximum Capacity
550 kg;1,250 lb
Cable {Length}
5 m
Cable {Length}
16.4 ft
Criticality
Standard
Environment / Material
Normal / Carbon Steel
Accuracy
Standard
INQUIRY
Get a tailored quote for the Weigh Module SWB220 CS 1.25K.
Tell us the application, throughput, and any compliance requirements. An LDY account manager assigned to Food & Feed will respond within one business day.
